45ZYN68-2420

24

2000

0.18

1600

42

7

0.5

220

2.0

45ZYN68-2430

24

3000

0.25

2400

65

16

1.2

300

4.4

45ZYN68-2440

24

4000

0.30

3200

90

30

2.0

375

6.8

Number of gear trains

1

1

2

2

2

3

3

3

3

4

4

4

Length(L) mm

35.3

35.3

45.6

45.6

45.6

58.4

58.4

58.4

58.4

68.7

68.7

68.7

No-load speed      r/min

539

386

143

105

74

39

28

20

14

11

7.6

5.4

Rated speed        r/min

431

309

114

84

59

31

22

16

9.5

8.5

6

4.3

Rated torque        N.m

0.14

0.20

0.34

0.65

0.92

1.6

2.2

3.1

4.2

5.2

7.3

10

N.m Max. permissible load in a short time

3

3

12

12

12

25

25

25

25

30

30

30

Number of gear trains

1

1

2

2

2

3

3

3

3

4

4

Length(L) mm

35.3

35.3

45.6

45.6

45.6

58.4

58.4

58.4

58.4

68.7

68.7

No-load speed      r/min

809

579

214

158

111

59

42

30

22

16

11

Rated speed        r/min

647

463

171

126

89

47

34

24

17

13

9.5

Rated torque        N.m

0.22

0.30

0.74

1.0

1.4

2.4

3.4

4.7

6.6

8.1

10

N.m Max. permissible load in a short time

3

3

12

12

12

25

25

25

25

30

30
